Automatically Detected Syringe Sizes

All brands, User selectable major brands and manual calibration of local brands

Models

Normal, KVO, Bodyweight mode & patient control Anaelgesia

Flowrate Range

10 m1=0.1 ml/hr-300.0 ml/hr,
20 m1=0.1 ml/hr-400.0 ml/hr,
50/60 m1=0.1 ml/hr-1000 ml/hr

Least Count In Flowrate

0.1ml/syringe

Syringe Size Auto-Detection

Yes

Drug Name

24 drug library

Alarms

Near Empty, Over Occlusion, Syringe Dislocation Malfunction, Low Batt, Low Batt Shutting down

Occlusion

a. Low= 300+/-100mm Hg (40.7 +/-13.3 KPa)

b. Medium = 500 +/-100mm Hg (66.7+/-13.3 KPa)

c. High = 800+/-200 mm Hg (106.7+/-26.7 KPa)

Total Volume Range

0.1 m1-9999 ml

Bolus

Auto & Manual

a. 1000 ml/hr for 50/60 ml syringe

b. 300 ml/hr for 10 ml syringe

c. 400 ml/hr for 20 ml syringe

Drug Delivery chart

Starting date & time,

Ending date& time,

drug name, Infusion rate set

Dimensions

(262x 130x 125) in mm

Weight

2.4 Kg

Type

Color TFT display

Size

2.8" Diagonally

Resolution

240 (RGB) x 320 Pixels

Power Input

110-260VAC, 47-63 Hz

Inbuilt Battery Type

 Li-ion

Battery Rating

 7.4V/2200 mA

Charging Time

 6 Hours

Operating Time

 4 Hours

Power Consumption

15 Watt

Operating Temperature

0  to 45°C

Storage Temperature

-10 C to 55°C

Operating & Storage Pressure

86-106 KPa

Operating & Storage Relative Humidity

20 -90 % Non condensing
